Place of Origin: | China |
Nama merek: | Kutai |
Sertifikasi: | CE / Rohs |
Model Number: | GCU-10 |
Minimum Order Quantity: | 1 piece |
---|---|
Harga: | negotiation |
Packaging Details: | Packaging with product box first, and then by Courier carton |
Delivery Time: | Within 3 working day after receiving the payment. |
Payment Terms: | L/C, T/T, Western Union, MoneyGram, Paypal |
Supply Ability: | 3000 pieces per Month |
DC supply: | 9V to 36V | Frequency: | 50~60 Hz |
---|---|---|---|
Panel Installation Cut-Out: | 66.0 x 66.0 ±0.5 mm | Power Consumption: | Under 3 VA on Auto |
Alternator Input Range: | Voltage 5~300 VDC | Engine Idle (Governor): | 0~300 Sec. |
Engine Pre-Heat: | 2~30 Sec. | Operation Temperature: | -20~70 °C |
Relative Humidity: | Maximum 90% | ||
Cahaya Tinggi: | bagian diesel generator,regulator tegangan otomatis untuk generator |
Kutai GCU-10 Gubernur Mesin Elektronik unit pengendali kontrol Generator, DC Supply: Tegangan 9-36 VDC
fitur
spesifikasi
DC Pasokan | Tegangan 9-36 VDC |
Alternator Rentang Masukan | Tegangan 5 ~ 300 VDC Frekuensi 50 ~ 60 Hz |
Keluaran bahan bakar Solenoid Signal | 5 Amp @ 12/24 VDC |
Mulai Signal output | 5 Amp @ 12/24 VDC |
Pemanasan Signal output | 5 Amp @ 12/24 VDC |
Aksesori "ON" Output | 5 Amp @ 12/24 VDC |
Menganggur Kontrol Konduktor Kapasitas | 5 Amp @ 12/24 VDC |
Konsumsi daya | Di bawah 3 VA pada Auto |
Indikator Status perlindungan & Alarm |
|
Timers adjustable | Mesin Pre-Heat: 2 ~ 30 Sec. Starter cranking Waktu: 1 ~ 15 Sec. Berikan energi untuk STOP: 1 ~ 30 Sec. Mesin idle (Gubernur): 0 ~ 300 Sec. Mesin Cool-down: 0 ~ 300 Sec. |
Lingkungan Hidup | Suhu operasi: -20 ~ 70 ° C Kelembaban relatif: Maksimum 90% |
Instalasi Panel Cut-Out | 66,0 x 66,0 ± 0,5 mm |
Ukuran | 72.0 (L) x 72.0 (W) x 50,0 (H) mm |
Berat | 166g ± 2% |
Kami menyediakan Control Panel Kutai Series sebagai berikut:
Unit kontrol Generator
AMF-10 GCU-20 DSP-10 DSP-30 DSP-52 ECU-02
ECU-04 / ECU-05 GCU-10 GCU-100 GCU-2000
GCU-3000 RA-20
Aksesoris Generator kontroler
AMF-10R ECU-11 / ECU-22 ECU-40 GCU-11r
KCU-01 / KCU-02 / KCU-03
PTU-03 PS-01 TS-01
